vmc 850 milling machine
High-precision spindle from Taiwan
Oil-water separation design
Servo motor-driven system
Contact Us Schedule a visit Inquire for a quote
The VMC 850 milling machine adopts a servo-driven, direct-drive semi-closed-loop vertical structure for the X, Y, and Z axes. All three axes are equipped with high-rigidity box guideways featuring excellent load-bearing capacity, while the worktable supports loads of up to 500 kg. To prevent deformation during machining, all cast components undergo thorough annealing to eliminate internal stress.
The machine is capable of machining a variety of complex parts, including discs, plates, housings, cams, and molds, in a single setup. It supports multiple machining operations such as drilling, milling, boring, reaming, and rigid tapping, making it suitable for high-mix, small- to medium-batch production.
Professional Technical Communication
Our engineering team supports customers with:
Machining solution recommendations
Technical drawings review
Fixture and tooling suggestions
Process optimization advice
Detailed Display
The CNC milling machine is equipped with ultra-low-inertia servo motors and a three-axis linear guide design, enabling a maximum rapid traverse speed of 48 m/min on each axis and significantly improving machining efficiency.
The VMC 850 milling machine features an automatic lubrication system that delivers timed oil supply to the guide rails and lead screws, preventing thermal expansion and extending service life.
The widened worktable and fully enclosed guide rail covers effectively prevent chips and debris from accumulating on the guide rails, ensuring long-term machining accuracy.
The disc-type tool magazine accommodates up to 24 tools, supports a maximum tool weight of 7 kg, and delivers a tool-to-tool change time of approximately 1.8 seconds.
| Model | VMC850 |
| Table size (mm) | 1000X500 |
| Allowable maximum load (Kg) | 500 |
| X-axis travel (mm) | 800 |
| Y-axis travel (mm) | 500 |
| Z-axis travel (mm) | 500 |
| T-slot | 5-18-108 |
| Distance from spindle center to Z-axis rail surface (mm) | 552 |
| Distance from spindle end face to work table (mm) | 110-610 |
| Spindle taper | BT40-140 |
| Spindle speed (r/min) | 8000 |
| X/Y/Z rapid movement (m/min) | 48/48/48 |
| Machine weight (Kg) | 5300 |
● Optional configuration
Contact us! We offer flexible machine configurations based on your machining requirements:
| Option | Available | Option | Available |
| 3 Axis |  |
Automatic tool changer (ATC) | |
| 4th Axis Rotary Table | |
Spindle center cooling system | |
| BT40/ BT50 Spindle | |
Custom fixture solutions | |
| Linear Guideway | |
Automation integration | |
| Box Way Structure | |
Screw/chain chip conveyor | |
| High-Speed Spindle | |
Electrical enclosure air conditioning | |
| Fanuc / Siemens / Mitsubishi CNC | |
Oil cooler | |
VMC 850 milling machine fourth axis
The fourth axis of a machining center is a rotary table added to the conventional three-axis machining system, commonly referred to as a rotary axis. By adding a fourth axis, the workpiece can achieve precise 360° rotation without repeated disassembly and re-clamping. A single setup enables multi-directional machining of the workpiece, including circumferential surfaces, end faces, angled holes, helical grooves, and circular grooves. This makes it an ideal upgrade solution for machining complex multi-sided parts such as shafts, discs, and box components. It is widely used in the precision machinery, automotive parts, hardware, and mold industries.
Finished Products of CNC Milling
VMC milling machines are ideal for precision machining applications involving aluminum components, mold parts, steel workpieces, flanges, cavities, and automotive components.
Strict Quality Control
Each machining center undergoes comprehensive quality inspection and performance testing prior to shipment, including spindle dynamic balancing, ball bar accuracy testing, laser calibration, and trial machining verification.
We place strong emphasis on machine reliability, as consistent performance directly affects production efficiency, operating costs, and delivery schedules.
Long-Term After-Sales Support
Online Technical Support
Our engineers provide remote technical support, covering machine operation, parameter settings, alarm diagnostics, and process optimization. Customers can quickly obtain assistance through online meetings, online communication, and technical documents.
01
Maintenance Guidance
We offer comprehensive maintenance support covering routine servicing, preventive maintenance planning, lubrication and inspection procedures, and maintenance guidance for the spindle, tool magazine, and CNC control system.
02
Spare Parts Supply
We provide long-term spare parts support for commonly used and critical machine components, including spindle assemblies, servo motors and drives, tool magazine components, electrical parts, sensors, switches, and CNC system accessories.
03
Remote Troubleshooting
Our technical team can quickly identify equipment issues and provide effective solutions, including CNC alarm analysis, electrical system diagnostics, servo and spindle troubleshooting, parameter backup and recovery, and software and control system support.
04
Training Assistance
We offer technical training in machine operation, CNC programming, tool selection, basic maintenance, machining processes, and safe operating practices.
05
Learn about the complete service plan!
