Automobile brake disc high speed vertical lathe
KD500 Double Column CNC Vertical Lathe Equipment Introduction
The KD500 Double Column CNC Vertical Lathe is an advanced piece of machining equipment that is designed for precision and accuracy. This machine is ideal for a variety of industries, including aerospace, automotive, and oil and gas.
One of the key features of the KD500 Double Column CNC Vertical Lathe is its two-column design. This design provides high stability and rigidity, ensuring that the machine can handle heavy-duty cutting and machining tasks with ease.
The machine also features a powerful spindle, which delivers high torque and speed for efficient and precise machining. This spindle is equipped with a precise positioning system, which allows for accurate and consistent cutting performance.
In addition to its powerful spindle, the KD500 Double Column CNC Vertical Lathe is also equipped with a high-resolution linear scale feedback system. This system provides accurate feedback on the machine's position and movement, which ensures precise cutting and machining.
The machine also features a user-friendly control system, which allows for easy programming and operation. This system is designed with a simple interface, which makes it easy for operators to quickly learn how to use the machine.
All of these features come together to make the KD500 Double Column CNC Vertical Lathe a powerful and versatile piece of equipment that is ideal for a wide range of applications. Whether you need precision cutting for aerospace parts or heavy-duty machining for oil and gas equipment, this machine is up to the task.
Overall, the KD500 Double Column CNC Vertical Lathe is a top-of-the-line machine that combines precision, power, and versatility. If you're looking for a reliable and efficient machining solution, this machine is definitely worth considering.
| Specification | unit | KD500 | Specification | unit | KD500 |
| X axis X 轴行程 |
mm | 300 | Turret station 刀塔工位 |
Four stations/eight stations 四工位/八公位 |
|
| Z axis Z轴行程 |
mm | 500 | X-axis rolling linear guide X轴滚动直线导轨 |
3 pieces, width 55mm 3 个,宽度 55mm |
|
| Maximum turning diameter 最大回转直径 |
mm | Φ650 | Z axis rolling linear guide Z轴滚动直线导轨 |
4 pieces, width 55mm 4 个,宽度 55mm |
|
| Maximum processing diameter 最大加工直径 |
mm | Φ500 | cooling motor 冷却电机 |
W | 450+750 |
| turning height 加工高度 |
mm | 500 | Pump output 泵输出 |
m³/h | 4m³/h |
| Spindle speed 主轴转速 |
rpm | 100-1000 | Repeatability 重复精度 |
mm | ±0.003 |
| Spindle motor power 主轴电机功率 |
Kw | 30 | positioning accuracy 定位精度 |
mm | ±0.006 |
| Spindle diameter 主轴直径 |
mm | Φ160 | smallest positioning unit 最小定位单元 |
mm | 0.001 |
| Chuck model 卡盘类型 |
hydraulic chuck 液压卡盘 |
Dimensions (approx.) 尺寸(约) |
mm | 2800*2400*2910mm | |
| diameter 直径 |
inch | 15″ | Gross weight (approx.) 重量(约) |
kg | 10000 |
